Water Cooling Automatic Induction Cap Sealer LGYS-1500B

Rate this item
(0 votes)
  • Inversed U shape channel bring more flexible for different closure style.
  • All electric device hermetic sealed in the cabin
  • lower EMI and resistant for dust in working area.
  • Over heat, over currency protect with lights indicate
  • Adjustable seal head's height that suitable for different containers' application.
  • Stainless Steel for easy to do clean & maintenance.

Additional Info

  • Suit Dia.: 20 mm-50 mm| 0.8" -2.0"
  • Efficiency: 200bottles per min (e.g.:PE bottle, Cap dia.32mm, Body Dia.38mm, H40mm, distance from foils to heating board 2mm)
  • Power: 1500 W
  • Voltage & Frequency: 220V/50Hz or 110V/60Hz
  • Working By: Automatic
  • Cooling By: Water
  • Conveyor & Speed: option | 12m/min
  • Height to Induction Coil: 40mm - 300mm | 1.6" - 11.8"
  • Machine Dimension: Control Unit: L540 x W460 x H1300mm |L 21.3" x W 18.1" x H 51.2" Conveyor: L1560 x W540 x H980mm |L 61.4" x W 21.3" x H 38.6"
  • Shipping Dimension: Package 1:L1400 x W560 x H660mm 55.1” x 22” x 26” Package 2:L1660 x W600 x H530mm 65.4” x 24” x 21”
  • Net Weight: 148.00 kgs | 326.2 lb.
  • Gross Weight: 210 Kgs | 463 lb.
